Model JC Series

A snap-action thermal control which is part of Portage Electric’s Valstat Series™ designed as a cost effective solution for protection in motor, transformer, and lighting applications.  Available with various bimetallic elements to match the current sensitivity of the device to the application.

Features

• Snap action device, quick break/quick make switching action.
• Conductive bimetal construction: The bimetallic element carries the circuit current for maximum sensitivity under short circuit conditions.
• Available in two bimetallic resistance values.
• Preset calibration, not adjustable in the field.
• Available with same end termination (JCA) opposite end termination (JCB)
• Gasketed zinc plated steel case suitable for many varnish impregnation processes.
• Case electrically live, insulating sleeving is available.
• Available with various leads and terminations including nickel strip for rechargeable battery packs.

Contact Ratings

• 22 amps 115 VAC inductive
• 8 amps 250 VAC inductive
• 20 amps 16 VDC inductive
• UL & C-UL Recognized Component
• VDE Certified

Calibration Range

• Available with nominal calibration temperatures from 60°C to 150°C.
